PRIDE 20" (451mm) Control V2 Disc Helium M21 Axes 10/15mm Blue Wheel Set

The PRIDE Control V2 Disc Helium M21 Wheel Set is developed for BMX Race bikes with 20-inch 451 mm wheels seeking a high-performing, lightweight... Read more
Regular price 577,40 €
Regular price Sale price 577,40 €
View full details

Description

The PRIDE Control V2 Disc Helium M21 Wheel Set is developed for BMX Race bikes with 20-inch 451 mm wheels seeking a high-performing, lightweight and reliable package. It combines Helium 6069-T6 aluminium rims with CNC-machined Control V2 hubs, offering an excellent balance between stiffness, responsiveness and durability.

The rim benefits from the Arcos System® process, enabling precise internal design and optimisation of the aluminium's mechanical properties. Its low-profile 19 mm section promotes rapid acceleration, excellent manoeuvrability and an immediate response during race phases.

The Pride Racing Control V2 6061-T6 aluminium hubs feature high flanges to improve wheel stiffness. The rear system with 7075-T6 aluminium driver and 6 micro-toothed pawls delivers 180 engagement points for fast and efficient sprints.

The ISO6 disc mounting ensures compatibility with suitable braking systems, while the 10x100 mm front axles and 15x110 mm rear axles provide a robust and precise fit. The blue finish also lends a distinctive visual identity to the overall build.

With a contained weight of 1458 g per pair, this configuration combines lightness, dynamism and reliability for riders seeking high-performance BMX Race wheels. The 28 spokes per wheel reinforce the strength needed to withstand the demands of competition.

Ref: 15986272698748

Technical information

General Information
Product: BMX Race Wheelset
Model: PRIDE Control V2 Disc Helium M21
Diameter: 20" (451 mm)
Use: BMX Race competition
Brake type: Disc only
Hub colour: Blue
Main material: Aluminium
Total wheelset weight: 1458 g

Rim Specifications
Model: Pride Helium Expert
Material: 6069-T6 Aluminium
Construction: Double wall
Technology: Arcos System®
Rim height: 19 mm
Rim width: 25 mm
Number of spokes: 28
Valve type: Presta
Tyre compatibility: 20 to 34 mm
Compatible tyre sizes:
20 x 1-1/8"
20 x 1-3/8"
V-Brake compatibility: No

Front Hub
Model: Pride Control V2
Material: 6061-T6 Aluminium
Manufacture: CNC machining
Spacing: 10 x 100 mm
Number of holes: 28
Bearing: 15267
Disc mount: ISO6

Rear Hub
Model: Pride Control V2
Material: 6061-T6 Aluminium
Spacing: 15 x 110 mm
Thru axle: 15 mm (not included)
Number of holes: 28
Driver standard: Shimano
Driver: 7075-T6 Aluminium
Engagement system:
6 micro-toothed pawls
Engagement via 3 simultaneous pawls
180 engagement points
Disc mount: ISO6
Bearing: 6902

Detailed Weights
Front wheel: 615 g
Rear wheel: 843 g
Complete pair: 1458 g

Additional Information
Lock ring and spacers included for rear chainline adjustment
Rim tape not included
15 mm rear thru axle not included (frame-specific)
